3 Axles Gasoline Carbon Steel Oil Tanker Semi Trailer

The Starway 3 axles gasoline carbon steel fuel tanker trailer is a tough and reliable choice for heavy-duty fuel transport. It’s made from strong carbon steel and is welded together for extra durability.

The oval shape of the tank holds more fuel, and the strong ends keep everything sealed tight. Inside the tank, there are baffles and wave plates to keep the fuel from sloshing around, making the ride smoother and safer.

On top of the tank, there’s a protective frame with a manhole cover and overflow pipe for easy and safe fuel handling. The bottom of the tank is designed to connect easily to other fueling equipment.

To make it even more durable, the tank walls are thick and the inside is sandblasted and coated with zinc. This helps protect it from rust and wear, ensuring a long lifespan.

Overall, the Starway carbon steel tanker trailer is a strong and reliable choice for transporting large amounts of fuel.

The advantage of starway 3 axles oil tanker trailer

  •   Corrosion-Resistant Zinc Coating

    • The inner surface of the tank is sandblasted and coated with zinc, offering excellent protection against corrosion and extending the lifespan of the tanker.

    . Heavy-Duty Tank Walls

    • With tank walls thicker than 3.2 mm, the tanker is built to withstand rough conditions and high-pressure transport.

    . Safety-First Design

    • The tank is equipped with a protective frame, manhole cover, and overflow pipe, ensuring safe and easy handling of fuel during loading and unloading.

    . Customizable for Various Fuel Types

    • Perfect for transporting a wide range of liquid fuels, from petroleum products to chemicals, thanks to its durable, leak-proof construction.

Technical Specifications :

Dimension (L*W*H) : 13000*2500*3800mm
Material : Carbon Steel /Aluminum Steel /Stainless Steel
Apply : Fuel,oil etc Liquid Cargo Transporting Apply
Tire : 11.00R20,12R22.5,12.00R20,385/65R22.5 Trangle/Hankook/Brigestone brand
Axles : 13T/16/20/25 to BPW or Starway ,FUWA Brand
Tank Thickness : 5mm
Dish End Thickness : 6mm
Buffle Thickness : 4mm
Compartment : 1 to 9 (Customer Requirement )
Manhole : 3 sets,Aluminum,Anti-Explosion
Discharge Valve : 2-3 inch
Bottom Valve : 4 inch Aluminum
Discharge Pipe : 3 inch rubber hose,6mm/each
Hose Carrier : 2 pcs Carbon Steel/Aluminum
Kingpin : 2 inch or 3.5 inch JOST Brand
Brake system : Wabcoe Valve with air chamber
Landing Gears : Jost brand two-speed Manual operating heavy duty 28 ton
Suapension : Starway vehicle Bogie suspension,spring suspension,Air suspension
Extinguisher : 3mm,4mm,6mm diamond steel plate
Other parts : 2 tool boxes 2 spare tire carrier
Functions : Transport container,loose cargo,bulk cement,bulk rice,etc
Vehicle painting :KTL Electrophoresis painting and power spraying
Use these carbon steel fuel tank trailer specifications as a reference point. We can customize the design to meet any specific requirements.
